IP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar Inverter

Shenzhen First Tech Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

IP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar Inverter

Brand Name : 1stess

Model Number : TP8KH

Certification : CE, IEC

Place of Origin : China

MOQ : 1 piece

Price : To be negotiated

Payment Terms : L/C, T/T

Supply Ability : 2000 pieces per month

Delivery Time : 30 days

Packaging Details : carton box

Charging Mode : MPPT

Operating Temperature : -10°C To 50°C

Inverter Type : Off Grid inverter

Frequency : 50Hz/60Hz

Output Voltage : 250V-600V

Communication Interface : RS485/CAN/USB

Contact Now

Product Features:

1.Maximum efficiency of 97.8% and battery efficiency of 97.0%

2.Advanced parallel function

3.Maximum battery charge/discharge current of 50A

4.Multiple built-in protections, with optional AFCl

5.Maximum battery charge/discharge current of 50A

6.Large MPPT current, compatible with high-power solar panels

MODEL
TP5KH
TP6KH
TP8KH
TP10KH
Nominal Battery Voltage
250VDC-600VDC
Mounting Method
Wall Bracket
Battery Type
Lithium-ion/Lead-acid
Nos.of MPPT
2
2
2
2
Nominal Grid Voltage
380V/400V/415V,3W+N+PE
Battery Voltage Range
120V-600V
120V-600V
120V-600V
120V-600V
Rated Grid Frequency
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
Transfer Time
<10ms (typical)
<10ms (typical)
<10ms (typical)
<10ms (typical)
Nominal AC Output Power
3000W
3600W
4600W
5000W
Protection Degree
IP65
IP65
IP65
IP65
Max.AC Output Apparent Power
5500VA
6600VA
8800VA
11000VA
Weight
32Kg
Dimensions (W*H*D)
560mm*580mm*218.3mm
Warranty
5 Years/10 Years (Optional)
Display
LED,LCD

Technical Parameters:

IP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar InverterIP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar InverterIP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar InverterIP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar Inverter

IP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar InverterIP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar Inverter

IP65 Single Phase 5kw 6kw 8kw 10kw Hybrid Solar Inverter High Voltage 250V-600V Pure Sine Wave MPPT On/Off Grid Solar Inverter

Core Advantages Summary:

High - Efficiency Power Conversion Supported by:

Maximum PV - to - AC efficiency up to 97.8% (e.g., TP10KH), excellent European efficiency (e.g., 97.3% for TP5KH), and top BAT - to - AC efficiency of 97.0%. Value: Significantly reduces energy loss and improves energy utilization across power generation, storage, and consumption stages.

Flexible PV Input Adaptation Supported by:

MPPT operating voltage range of 160V–950VDC, max input current per MPPT of 20A/30A (model - dependent); supports 1–2 MPPT groups with 1–2 PV strings per MPPT. Value: Flexibly matches voltage characteristics and layouts of diverse PV arrays to maximize solar energy capture.

Wide Energy Storage Battery Compatibility Supported by:

Compatible with both Lithium - ion/Lead - acid batteries, with a battery voltage range of 120V–600VDC (nominal 250V–600VDC) and max charge/discharge current up to 15,000W/11,300W (e.g., TP10KH). Value: Compatible with mainstream energy storage solutions, meeting requirements for residential, commercial, and industrial scenarios.

Stable Grid Connection & Backup Power Supported by:

  • Grid - connected mode: Rated AC output power 5kW–10kW, apparent power 5.5kVA–11kVA; supports 380V/400V/415V grids (voltage adjustable to 260V–520V), frequency range 45Hz–65Hz (adjustable), power factor >0.99, THDi <5%.
  • Backup mode: Rated output power 5kW–10kW, mains transfer time <10ms (typical), peak apparent power up to 15kVA (10s duration). Value: Ensures grid interaction stability and continuous load power supply via UPS functionality.

High - Reliability Protection Design Supported by:

IP65 ingress protection (dust - and water - proof); integrated protections (anti - islanding, AC/DC overcurrent/overvoltage/short - circuit, DC reverse protection); compliance with Class I safety standards. Value: Withstands harsh environments and fully safeguards equipment and personnel.

Harsh Environment Adaptability Supported by:

Maximum operating altitude 4000m (derated when altitude >2000m), operating temperature range - 25℃–60℃ (derated when temperature >45℃), relative humidity 0–100%; natural cooling design with wall - mountable installation (weight 32kg). Value: Adapts to complex scenarios (plateau, severe cold, high temperature, humidity) and reduces deployment difficulty with lightweight design.

Intelligent Monitoring & O&M Supported by:

Optional LED/LCD display and mobile App; supports multiple communication interfaces (RS485/CAN for BMS, DRM, optional WiFi/LAN). Value: Enables local and remote monitoring, simplifying operation and maintenance processes.

Authoritative Certification & Warranty Supported by:

Compliance with international standards (IEC/EN 62109 - 1&2, IEC/EN 61000) and certifications (VDE 4105, EN 50549 - 1); optional 5 - year/10 - year warranty. Value: Internationally recognized technical reliability with extended after - sales support.
